- Place of Origin: Shandong, China (Mainland)
- Brand Name: yuzhuo
- Model Number: VL550
GSK218M * full enclosure machine guard
* Funnel type tool changer * automatic central lubrication system with alarm
* Z axis counter-balance weight * spindle cooling unit
* spindle side air blow * nozzle&coolant nozzle
* machine window with safety glass
* rigid tapping
* auto power off * 3 colours warning lamp
VL550---Linear guideways in 3 axes | ||
Travel | X axis | 550mm |
Y axis | 350mm | |
Z axis | 500mm | |
Spindle nose to table | 100-600mm | |
Spindle nose to column | 419mm | |
Feed | max X rapid feed | 48m/min |
max Y rapid feed | 48m/min | |
max Z rapid feed | 48m/min | |
Cutting feed | 1-10m/min | |
Torque | X:7 N.m Y:7 N.m Z:7 N.m | |
Table | Table size | 700×350mm |
Max load | 300Kg | |
Table surface to floor | 820 mm | |
T slot | 3×18×105mm | |
Spindle | Type | Belt |
Speed | 8000 rpm | |
Spindle taper | BT40 | |
Main motor | 5.5KW | |
Accuracy | Accuracy (JIS) | ±0.005/300mm |
Repeatability (JIS) | ±0.003mm | |
Other | Weight | 2600 Kgs |
Size | 2100×1900×2300 | |
